ns55 CrossFlash is not possible. jb9 pcb has additional chip.
ns60 quality test support locked? VinPower ns68?

lg Shorten the life of the product by using a single shaft instead of 2 miles, the writing quality is deteriorated by worn over time.
he has to go back 2 miles urgently.

Excellently .:spoko::spoko:
Shopping and shipping are very fast in your country ...:wow::wow::wow:

I see that it changed the design of the HLDS hardware NS50 \ 51 \ 55 \ 58 - motherboard of the new type JB9.
Chipset and laser no change = MediaTek MT1959HWDN + OPU Hitachi HOP-B711

Widzę że zmieniła konstrukcja w stosunku do hardware HLDS NS50\51\55\58 - płyta glówna nowego typu JB9 .
Chipset i laser bez zmian = MediaTek MT1959 + OPU Hitachi HOP-B711

Załącznik 101758

Załącznik 101757

Cytat:

Napisany przez zaq99 (Post 1389544)

ns60 Blu-ray quality test support ?

Ns50 crossflash ns60, uhd is likely to play.

Does the BU40N have an ATECC508A chip ns50 ns60?
http://www.microchip.com/wwwproducts/en/ATECC508A
http://www.atmel.com/Images/Atmel-89...et-Summary.pdf

https://www.digikey.com/product-deta...TCT-ND/5213074

Bdr-s11-211 uhd bd does not have a similar chip.

All factory versions of LG BluRay have blocked access to correction block and error information.
Only versions from VinPower LG BluRay will allow discquality tests.

It is difficult to say whether it is possible to crossflash between NS50 hardware and NS60 but in my opinion I doubt it. There would have to be identical hardware and software inside the drives.

We do not know the exact hardware of the Pioneer BDR-211 \ S11 so it's hard to tell how the AACS 2

Cytat:

Napisany przez czary2mary (Post 1389471)

Price is good?
You can buy now, order from you?

ns40 usa 63usd, Discount days down to 50USD.

Cytat:

Napisany przez czary2mary (Post 1389471)

Price is good?
You can buy now, order from you?

Yes, the drive is available to purchase here. I should have one tomorrow.

Cytat:

Napisany przez Berion (Post 1389507)

Co to jest Jameless Play?

Większość napędów DVD\ BluRay LG ma to na pokładzie :

Załącznik 101646

Co to jest Jameless Play?

Cytat:

Napisany przez jadburner (Post 1389470)

U.S. price is $120 for the WH16NS60.

Price is good?
You can buy now, order from you?

U.S. price is $120 for the WH16NS60.

Specyfikacja LG WH16NS60 Ultra HD Blu-ray

Specyfikacja

Cytat:

Type Blu-ray / DVD Writer

TRANSFER RATES - WRITE (MAX)

BD-R (SL) 16x ZCLV
M-DISC BD (BD-R SL / DL / TL) 4x CLV / 6x PCAV / 4x CLV
BD-R(DL) 12x CAV
BD-R (TL) 8x ZCLV
BD-R(QL) 6x ZCLV
BD-R (LTH) 8x PCAV
BD-RE (SL/DL/TL) 2x CLV
DVD-R (SL) 16x CAV
DVD-R (DL) 8x ZCLV
DVD+R (SL) 16x CAV
M-DISC DVD (DVD+R) 4x CLV
DVD+R (DL) 8x ZCLV
DVD+RW 8x ZCLV
DVD-RW 6x CLV
DVD-RAM 5x CLV
CD-R 48x CAV
CD-RW 24x ZCLV

TRANSFER RATES - READ (MAX)

BD-ROM (SL/DL) 12x CAV / 8x CAV
BD-R (SL) 12x CAV / 8x CAV
BD-R (TL/QL) 6x CAV / 6x CAV
BD-R (SL/LTH) 8x CAV
BD-RE (SL/DL) 10x CAV / 6x CAV
BD-RE (TL) 4x CLV
BDMV (AACS Compliant Disc) (SL/DL) 12x CAV / 8x CAV
BDMV(UHD)(DL / TL) 8x CAV / 8x CAV
DVD-ROM (SL/DL) 16x CAV / 12x CAV
DVD-R (SL/DL) 16x CAV / 12x CAV
DVD+R (SL/DL) 16x CAV / 12x CAV
DVD-RW 12x CAV
DVD+RW 12x CAV
DVD-RAM 5x CLV
DVD-Video (CSS Compliant Disc) (SL/DL) 12x CAV / 8x CAV
CD-R/RW/ROM 48x CAV / 40x CAV / 48x CAV
CD-DA 40x CAV

OTHER FEATURES

Silent Play Yes
Jamless Play Yes

ACCESS TIME (1/3 STROKE)

BD-ROM 180ms typ.
DVD-ROM 160ms typ.
CD-ROM 150ms typ.

SUSTAINED TRANSFER RATE

BD-ROM 53.94 MB/s (12x) max.
DVD-ROM 22.16 MB/s (16x) max.
CD ROM 7.2 MB/s (48x) max.

BUFFER SIZE BUFFER SIZE

4 MB Buffer Under-run prevention function embedded

HOST INTERFACE

Internal (Drive) SATA

COMPLIANCE

RoHS Yes
Safety UL UL 60950-1 Second Edition
C-UL CSA C222 No. 60950-1 Second Edition
TUV EN 60950-1 / EN60825-1
SEMKO EN 60950-1 / EN60825-1
EMC CE Marking, RCM, BSMI, FCCI, KC, CU, FCC Part 15 Class B Digital Device, ICES-003 Digital Apparantus
Laser Safety Class 1 laser product comply with DHHS rules 21 CFR Subchapter J Class 1 laser product to EN60825-q/IEC 60825-1

OPERATING SYSTEMS OPERATING SYSTEMS

Windows 10, Windows 8.1, Windows 8, Windows 7

UHD SYSTEM REQUIREMENTS CPU

Intel 7th Gen. Kabylake Core i3 or higher
GPU Intel HD Graphics 630 or higher
Chipset Intel SGX* / HDMI 2.0a / HDCP* 2.2 & 1.4 Support
O/S Windows 10
RAM Minimum 6GB
Network Need To Network Access
Display UHD (3,840 x 2,160 pixel) Resolution / HDMI 2.0a (HDR*) / HDCP* 2.2 & 1.4 Support

DIMENSIONS
(WxHxD) 5.7" x 1.6" x 6.5" ( W/O Bezel )
WEIGHT WEIGHT
1.4***177;0.1 Ib

LG WH16NS60\LG BH16NS60 Ultra HD Blu-ray

HDLS zapowiedziało pierwszy swój model Ultra HD Blu-ray na swojej oficjalnej amerykańskiej stronie firmowej
http://www.lg.com/us/burners-drives/lg-WH16NS60

Załącznik 101545

Aktualizacja 08.10.2017

Jest już oficjalna zapowiedź wersji LG BH16NS60 na oficjalnej Koreańskiej stronie koncernu LG .
Również oficjalnie rozszerzamy temat o ten model :)

http://hlds.co.kr/product_info/?top=...=2&ckattempt=1

Załącznik 104665
